Product Description
Alarm system:
Astern voice alarm system
Secondary operating system:
The tail is equipped with an electronic control operating system to control the lift of the large car and the rear door switch, so as to avoid safety accidents caused by the user's observation of the rear situation in the cockpit.
Manual pump emergency lift system:
If the hydraulic system cannot be used due to the failure of the auxiliary engine, the brush, the suction cup, and the trunk can not be lifted, the emergency lifting system can be operated by the manual pump.
| Items | Descriptions | Specifications and Types |
| General | Truck Name | Sweeper-washer truck |
| Drive Type | 4x2 | |
| Gross Vehicle Weight(kg) | 23500 | |
| Curb Weight(kg) | 11500 | |
| Overall Dimensions L*W*H(mm) | 8350*2550*3130 | |
| Engine | Engine Brand | Cummins B190-33 |
| Fuel Type | Diesel | |
| Power | 140w/190HP | |
| Emission Standard | Euro III | |
| Displacement(ml) | 5900 | |
| Engine Type | 6 cylinders in line,4 stroke, water cooling, charged diesel engine, inter-cooling | |
| Chassis | Chassis Brand | Dong Feng Tianjin |
| Cabin | Flat roof, single row cab | |
| Front/Rear Axle(kg) | 5000/10000 | |
| Tire No. | 6+1 | |
| Tire Specification | 10.00R20 Steel tire | |
| Wheelbase (mm) | 4500 | |
| Axle No. | 2 | |
| Gear Box | FAST 8JS85E, 8 speed, manual | |
| Brake | Air brake | |
| Steering Wheel | Left hand drive with power-assisted | |
| Sweeping System | Garbage tank volume(m³) | 5 |
| Water tank volume(m³) | 7 | |
| Garbage & Water Tank material | Carbon steel with electrophoretic corrosion protection | |
| Sweeping width | More than 3m | |
| Brushes No. | 2 | |
| Auxiliary Engine Power | cummins 170hp | |
| Others | Sanyang motor; high-pressure water pump (front flush/side spray/center spray/rear spray/flushing water gun/trash can self-cleaning device); high-pressure curb cleaning nozzle, low-pressure pump (front flush); stainless steel trash bin; controller; control box ; PLC one-button control; tail LED arrow light; garbage bins and water tanks are equipped with anti-overflow and low water level alarm devices; indoor monitor for reversing and cleaning status. 15m high pressure washing reel | |
Packing and Shipping
01 CONTAINER: Put the vehicles into container, Maybe need disassemble, cheapest freight and fast shipping ;
02 FLAT RACK: Often used to ship medium equipment,max load-bearing is 35tons.
03 BULK CARGO SHIP: Which is better for bigger equipment,no need disassemble.
04 RO - RO :The machine is driven directly into the ship and does not need to be disassembled.
Founded in 2006, HENAN ULIKE INDUSTRY Co., Ltd. is a top package equipment solution provider in China, especially for Commercial Vehicle, Engineering Machinery, construction machinery, agricultural machinery, parts and so on
We Ulike industry are always committed to offer our customers high quality products with reliable performance, competitive price and comprehensive services, to ensure every engineering project to be run smoothly on schedule. With over Fifteen years' experience in the field of Commercial Vehicle, Engineering Machinery, construction machinery, agricultural machinery and accompanying to fulfill strictly ISO 9001: 2008 standard, we had established and have been consistently keeping good business relationship with many general contractors, civil engineering firms and construction companies throughout the world.
We Ulike industry participated as package equipment provider previously include airport projects in Africa, power plant projects in Middle East, dredging projects in South America, highway projects in Oceania, rural and municipal road projects in Southeast Asia, and we are still achieving more and more projects at present. To provide reliable products with quick delivery time, to make prompt reaction for spare parts and after-sales services, to visit the users field regularly for local training and maintenance, Ulike industry has been often praised by our customers and has taken great reputation as a trustworthy project partner. Ulike Inductry believe in combining our own achievement together with our customer benefits. Open communication, effective planning and elaborative preparation always commit us to execute and deliver our promises for our customers all over the world.
| Before-Sale | After-Sale |
| 1. Airport pickup, Booking hotel. | 1. Visiting the famous scenic spots in zhengzhou. |
| 2. Visiting our company yard, Enjoying Free test drive. | 2. 1-Year warranty for All the equipments |
| 3. Different machines to compare with each other. | 3. A lifetime of parts and technical support. |
| 4. Interpreting mechanical configuration information in detailed. | 4. Fast parts deliver and quick reply for any feedback . |
We guarantee that the moment the vehicle reaches you, our staft reaches you to ensure 24 hours' service.
Normally there will be 2-4 service engineers with the client
We have set up complete spare parts centers to satisfy the clientsand guarantee spare parts supply.
Q: Who are we?
Ulike industry is an international trade company established in 2006 and located in zhengzhou city, the center of china.Our company is one of the most powerful and potential commercial vehicles, used engineering equipment & construction Machinery suppliers in China, which has abundant experiences in exporting the machinery to the overseas customers. We win a high admiration and is widely trusted in Africa, Middle East, West Asia, South East and so on! The most important thing is that we have ability and would like to provide you high-quality products at competitve price all the time.
Q: How can we guarantee quality?
Make contract with customer.
Accept visting our yard all the time.
According to the customers request to do certificate.
Q: What is your delivery time?
A: The delivery time is within 15 working days.
Q: What is the payment term?
A: Normally we accept 30% deposit by TT for production, 70% balance by TT before shipping. Also can be the terms according your requirements
Currency: USA.EURO.CNY.
Q: Why choose us?
More than 15 years exporting experience with Asia, Middle East, South America and Australia all around the world. high-quality resources and channels provide the most cost-effective products, and 24 hours' service.
